2023 Polaris Sportsman 570 Trail
$500 OFF
Stock #4919
MSRP:
$10,599
USD
Discount:
$500
Your Price: $10,099 USD
STRONG
Relentless, job-ready features for the daily grind.
SMOOTH
Legendary Sportsman suspension delivers the smoothest ride to absorb bumps of all sizes.
Suspension
Independent rear suspension delivers more traction and helps you ride over even bigger obstacles.
VERSATILE
Best-in-class integrated storage and smart features for long days out. Plus, you can customize for your work or play needs with a wide selection of accessories.
- Status:New
- Vehicle:2023 Polaris Sportsman 570 Trail
- Model Number:A23SHY57AL
- Color:Onyx Black
- Stock Number:4919
- Location:Guy's Outdoor Motorsports & Marine
- Warranty:Manufacturer's w/ Extended Available
BRAKES
- Front Brake Type:Hydraulic Disc
- Rear Brake Type:Hydraulic Disc
DRIVE LINE
- Differential Lock Location:Rear
- Driveline Brand:On-Demand™
- Driveline Type:Selectable 4X2 / 4X4
- Limited Slip Differential Location:Rear
- Number Of Driveline Modes:2
ENGINE
- Bore (in):3.9
- Bore (mm):99
- Carburetion Type:Fuel Injected
- Compression Ratio:10
- Cooling:Liquid
- Cylinders:1
- Displacement (cc):567
- Displacement (ci):34.6
- Engine Brand Name:ProStar™
- Engine Stroke:4-Stroke
- Engine Type:Single-Cylinder
- Fuel Injector:Yes
- Fuel Requirements:Regular
- Fuel Type:Gas
- Horsepower (bhp):44
- Horsepower (kW):32.8
- Starter:Electric
- Stroke (in):2.9
- Stroke (mm):73.6
- Valve Configuration:DOHC
- Valves Per Cylinder:4
- Valves:4
EXTERIOR
- Bash Plate (Front):Yes
- Body Material:Composite
- Brush Guard:Yes
- Floor Board Location:Driver
- Frame:Steel
INSTRUMENTATION
- Fuel Level Warning Type:Gauge
- Temperature Warning Type:Gauge
LIGHTS
- Type:LED
SEATS
- Number Of Seats:1
- Seat Height (in):33.3
- Seat Height (mm):845
- Seat Location:Driver
- Seat Material:Vinyl
- Seat Type:One-Piece
STEERING
- Steering Control:Handlebar
- Steering Type:Power
STORAGE
- Capacity (kgs):40.8
- Capacity (kgs):81.6
- Capacity (lbs):180
- Capacity (lbs):90
- Rack Rails Location:Front
SUSPENSION
- Front Suspension Type:Independent Double A-Arm
- Front Travel (in):8.9
- Front Travel (mm):226
- Number Rear Shock Absorbers:2
- Rear Adjustable Shock / Spring Pre-Load:Yes
- Rear Suspension Material:Steel
- Rear Suspension Type:Independent Double A-Arm
- Rear Travel (in):9.5
- Rear Travel (mm):241
TECHNICAL SPECIFICATIONS
- Dry Weight (kg):396
- Dry Weight (lbs):873
- Engine Displacement to Weight (cc):0.65
- Fuel Capacity (gal):4.5
- Fuel Capacity (l):17
- Ground Clearance (in):11.5
- Ground Clearance (mm):290
- Height (in):47
- Height (mm):1194
- Length (ft):6.92
- Length (ft/ft):6
- Length (ft/in):11
- Length (in):83
- Length (mm):2108
- Payload Capacity (kgs):220
- Payload Capacity (lbs):485
- Towing Capacity (kgs):612
- Towing Capacity (lbs):1350
- Wheelbase (in):50.5
- Wheelbase (mm):1283
- Width (in):48
- Width (mm):1219
TOWING & HAULING
- Rear Hitch Type:Receiver
- Size (cm):3.2
- Size (in):1.25
TRANSMISSION
- Hi / Low Range:Yes
- Primary Drive (Engine / Transmission):Belt
- Primary Drive (Front Wheel):Shaft
- Primary Drive (Rear Wheel):Shaft
- Reverse:Yes
- Transmission Brand:Polaris Variable Transmission (PVT)
- Transmission Type:Continuously Variable (CVT)
WHEELS & TIRES
- Front Tire (Full Spec):Duro Power Grip
- Front Tire Diameter (in):26
- Front Tire Width:8
- Front Wheel Diameter:12
- Rear Tire (Full Spec):Duro Power Grip
- Rear Tire Diameter (in):26
- Rear Tire Width:10
- Rear Wheel Diameter:12
- Wheels Composition:Aluminum
